Cabo Steel Square Gas Fire Pit - Outdoor Plus

A Modern Fire Pit Masterpiece

Named for the picturesque resort city in Baja California, the Cabo Fire Pit by The Outdoor Plus is a striking patio statement piece and features a squared design built by hand from commercial-grade steel. The steel is then powder coated and finished in your color selection. Includes lava chunks.

Other pieces in this series:

• Cabo Metals Collection Fire Pit (Copper, Stainless Steel, Corten Steel)
• Cabo Concrete Fire Pit

Make Memories with Friends & Family

Unwind. Dream. Share. Laugh. Each Cabo Steel Fire Pit is individually hand built, offers a significant weight savings over concrete, and provides a beautiful centerpiece for a solo retreat or lively gathering place. Multiple ignition systems and finish options available.

Authorized Accessories

• Bullet Burner® (confirm Burner size in Specs table below)

Why You'll Love This Concrete Fire Pit

• Made in the USA: At a family-run business on the West Coast
• High-Strength Materials: For durability, longevity and exceptional quality
• The Latest Burner Technology: Check out the optional Bullet Burner® upgrade
• Individually Hand Built: Skilled craftsmen create each fire pit with the same level of passion
• Uniquely Yours: Due to its handmade nature, slight variations in color and texture may occur and no two pieces are the same

FOR OUTDOOR USE ONLY. 1) Installation and service must be performed by a qualified installer, service agency, or the gas supplier. 2) It is not recommended to use glass media with Liquid Propane. Propane is 1.5x heavier than air, and the denseness of decorative glass may cause propane to pool underneath and create a potentially dangerous situation.

Ignition Systems – Take Time to Compare

Match Lit Learn more

Traditional system that connects to your fuel source and valve. To operate, simply open the fuel supply valve and light the burner with a matchstick or lighter. Then, slowly turn on the fuel valve.

⚙ Includes: Pan, Burner, Gas Orifice, Gas Hoses, Key Valve, Key.

Match Lit w/Flame Sense (LC Certified) Learn more

A match-lit system fitted with a thermocouple flame sensor for an extra layer of protection against leaks or buildups. To operate, you'll light the fire pit with a control knob and ignitor button. If the sensor doesn't detect a flame, the fuel supply will automatically close.

⚙ Includes: Pan, Burner, Gas Orifice, Gas Hoses, Key Valve, Key, Flame-Sensing System.

Plug & Play Electronic 30 DC (CSA Certified)

⚠ Min. 5FT away from water

Learn more

110V Smart Weather Electronic Ignition System (SWEIS) turns the flame on and off by a switch. Simply plug into a standard 3-pronged outlet. Glow plug pilot uses a Hot Surface Igniter (HSI) for ignition and a thermocouple flame sensor to close the fuel supply when a flame isn't detected.

⚙ Includes: Pan, Burner, Gas Orifice, Gas Hoses, Key Valve, Key, Plug & Play Electronic Valve, Flame Sensor, Pilot Igniter.

12V Electronic Low Voltage 30 DC (CSA Certified)

✓ Safe for use within 5FT of water

Learn more

Turn the fire on and off by a convenient switch. Can be wired by an electrician to be controlled by a pool controller, remote control, or home automated system. Compatible with 12VAC only (but includes a 12V to 110V transformer). Features a glow plug igniter that withstands the elements.

⚙ Includes: Pan, Burner, Gas Orifice, Gas Hoses, Key Valve, Key, 12V/24V Transformer, Electronic Valve, Flame Sensor, Pilot Igniter.

Specifications

Fuel: Natural Gas or Liquid Propane
Material: Powder coat stainless steel
Color: Choose from the designer palette provided

Model	Dimensions	Burning Area	Burner	BTU	Fire Media
OPT-CBSQ36PC	36" sq. x 16"H 90 lbs.	20" sq.	12" Round	65K	50 lbs.
OPT-CBSQ48PC	48" sq. x 16"H 125 lbs.	28" sq.	18" Round	160K	75 lbs.
OPT-CBSQ60PC	60" sq. x 16"H 180 lbs.	40" sq.	24" Round	190K	75 lbs.

Warranty	Warranty varies by component — up to Lifetime on burners, up to 5 years on pans. Full details in the Resources Hub.
Spec Sheet	Cabo Fire Pit Spec Sheet (PDF)
